OBDSTAR D800 Full Configuration | Marine Diagnostic Tool | Jet Ski-Outboard-Inboard-Generator

Description

OBDSTAR DC706

OBDSTAR DC706 ECU tool is designed for vehicle ECM, TCM and body/other system for ECU flasher.
It can read ECU info, R/W Eeprom/Dflash/Pflash/MAP, reset ECU(Virgin), calibrate mileage, read IMMO pincode, ECU recovery…
It’s all by OBD or bench mode and makes ECU cloning easy.

Functions

ECU Clone/ All by OBD or Bench

• ECM clone for cars(Bosch, Continental, Delphi, Denso, Magneti Marelli, Siemens…)
• ECM clone for motorcycles(Bosch, Delphi, EFI…)
• TCM clone(Ac Delco, Bosch, Continental, Getrag, GM, Kefico, Siemens, Temic, ZF…)
• Body/Other clone(FCA, FIAT, FORD, GM/OPEL, LAND ROVER/JAGUAR, PSA, SMART, VOLVO…)

Supported ECU Manufacturers

Supported Brands

Advanced Functions

1. R/W eeprom/dflash/pflash/Map, reset ECU(Virgin), calibrate mileage, read IMMO pincode, ECU recovery…
2. Support 1200+ ECM types(Partial functions require P003 adapter.)
3. Support 280+ TCM types
4. Support 130+ body/other ECU types(AIRBAG, BCM, BSI, CEM, DDM/PDM, DIM, EPS, KeyLess(RFHUB/RFHM), KVM, RFA, SAM…)
5. Support VW DQXXX (TCM) calibrate mileage
6. Support motorcycle Delphi MT05, MT05.2, MT05.3 ECU clone
7. Support motorcycle BRP ME17.8.5 ECU clone (works with P003 adapter)
8. Support Piaggio series engine ECU clone(such as MIU G4 (M4G1))
9. Support intelligent search by brand, model, part No., ECU manufacturer, MCU controller type
10. Support automatic identification
11. Strong help data files
12. All by OBD or Bench mode

SPECIFICATIONS;
