Description
USB-LINK 3
The Nexiq USB-Link 3 is a new, more capable USB-Link that supports CAN FD and DoIP protocols while providing the compatibility for a wide range of OEM diagnostics software. Designed for flexibility, the USB-Link 3 Wireless Edition connects to your PC, tablet, or smart phone, via Bluetooth and Wi-Fi. In addition, the USB cable gives techs the option to directly connect to a PC when working in the field or during signal interruptions.
Features
- Compatible with iOS, Android™, and Windows®
- Interfaces with USB 2.0 (vehicle-to-PC connectivity), Bluetooth® 2.1 + EDR, and Wi-Fi (dual band)
Vehicle Network Protocol Support
- CAN FD / J1939 FD / ISO15765 FD – 250K, 500K, 1M b/s with auto baud detection
- Single wire CAN (SWCAN)
- ISO 11898-3 Fault Tolerant CAN (FTCAN)
- Diagnostics Over Internet Protocol (DoIP)
- J1708
- J1850 VPW (Class 2)
- ISO PWM (SCP)
- ISO 9141 / KWP2000 (ISO 14230) K/L line
- ALDL 9600 and 8192 baud
- ATEC 160 baud
Windows® Vehicle Communication API
- Windows® Vehicle Communication API
- RP1012 a/b/c
- J2534 (2004 draft)
- J2534-1 partial implementation (commercial vehicle focused)
Compatible Software (Not Included:)
- Detroit Diesel Diagnostic Link
- CAT Electronic Technician (On-Highway only)
- Cummins Insite
- International – ServiceMAXX Fleet Pro
- Hino eXplorer
- Volvo PTT
- VCAD Elite Mack/Volvo
- V-MAC Service Tools
- Allison DOC® For PC-Service Tool – Protocols Supported: J1939, J1708/J1587, and J1850
- Allison DOC® For Fleets (1000/2000) – Protocols Supported: J1939, J1850
- Allison DOC® For Fleets (3000/4000) – Protocols Supported: J1939, J1708/J1587
- Eaton Service Ranger
- Bendix ACom
- WABCO Toolbox
- Freightliner ServiceLink
- International ABS
- International DLB
- International Intune
- International IPC v2.02
- PACCAR DAVIE4
Sofia Kovalev (store manager) –
The USB-Link 3 is incredibly fast compared to the old USB-Link 2. It connects seamlessly with Cummins Insite and Detroit Diesel Diagnostic Link without dropping data streams. The upgraded RAM handles heavy bus loads effortlessly
Kai Tanaka (store manager) –
The tool itself is a solid 5 stars. Build quality is very rugged, and the latching USB cable is a nice touch so it doesn’t accidentally pull out mid-config. Dropped it to 4 stars only because you need to make sure your Windows drivers are 100% updated to get the RP1210 and J2534 protocols running smoothly. Once configured, it’s flawless
